Product information to download

Want to find out more about our high quality products?  You can download our technical bulletins right here.

Download our technical bulletins

If you want to be automatically informed of any new Technical Bulletin releases or if you need something right away and it isn’t in our download section then click here and visit our news page where to you can subscribe to updates by email.

Neck Ring Mechanism

Neck Ring Mechanism

The latest Lattimer Neck Ring Mechanism has increased its accuracy and the closing speed of both cylinders, plus many more performance upgrades.

(File type: PDF, Size: 161.47 KB)
DOWNLOAD
Takeout Arm (For Servo Machines)

Takeout Arm (For Servo Machines)

Lattimer Take Out Arm for Servo Machines is designed to cope with the most challenging of operating speeds. All sizes available as belt or chain driven.

(File type: PDF, Size: 710.54 KB)
DOWNLOAD
Take Out Arm

Take Out Arm

As the inventor of the original belt Take Out Arm, Lattimer continue to create high performance take out solutions. As the market leader, our Take Out Arms are still setting the standard where others struggle to match.

(File type: PDF, Size: 147.54 KB)
DOWNLOAD
Take Out Assembly

Take Out Assembly

Lightweight, aluminium Take Out Assembly for the precise and repeatable pick up and placement of containers.

(File type: PDF, Size: 166.41 KB)
DOWNLOAD
Quick Change Blowhead

Quick Change Blowhead

A lightweight Blowhead assembly, made from high quality aluminium billet for strength and accuracy. Equipped with a steel Quick Change Adaptor to provide secure clamping and eliminate problematic casting failure.

(File type: PDF, Size: 944.16 KB)
DOWNLOAD
X-Y Adjustable Tong Head Assembly

X-Y Adjustable Tong Head Assembly

Achieve total accuracy in tong to mould alignment and eliminate pick-up related faults with the Lattimer Quick Change X-Y Adjustable Tonghead.

(File type: PDF, Size: 547.36 KB)
DOWNLOAD
Linear Action Tong Holder

Linear Action Tong Holder

The Linear Action Tong Holder provides a consistent pickup with cushion closing reducing wear defects and increasing efficiency.

(File type: PDF, Size: 1.1 MB)
DOWNLOAD
Quick Change Baffle Head

Quick Change Baffle Head

Designed with optimised airflow, the Baffle Head assembly allows for a reduction in finish set time through the improved equalisation of cavity air pressure.

(File type: PDF, Size: 268.92 KB)
DOWNLOAD
